4 Ton 5 Ton Diesel Forklift with Price Can Be Customized

Share to:

3 Ton Engine Diesel Forklift for Sale

Availability:

Quantity:



Inquire Add to Basket

Model:
CM-DF5T-A
Brand:
Cheerong

Product Description

Product Description

The core components of the A series 4-5t internal combustion forklift have been fully verified by the market and are mature and reliable. The whole machine integrates the research and design concepts of "safety", "reliability", "efficiency" and "comfort", combines CheersMetal's many years of technical exploration and design innovation in the field of internal combustion forklifts, adds the latest technology and process development results, and highlights the traditional attributes of durability and high cost performance.
Hard-core configuration is more complete
·Equipped with a variety of powerful low-emission engines, you can drive as you like.
·The reinforced drive axle has high casting precision and stronger axle body.
·The soft-connect gearbox has rich configurations, which have been fully verified by the market and are mature and reliable.
·Reinforced cast steering axle has high load-bearing capacity and long service life.

Optimized design and reliable
·The braking system has been fully upgraded and adopts hydraulic braking to effectively improve braking reliability and comfort.
·The wheelbase is lengthened and the load-bearing capacity is increased by 5%.
·The enlarged high-position air intake grille allows for smoother air intake and more complete engine utilization.
·The large LCD instrument panel comprehensively monitors the vehicle status.
·The portal frame channel steel is made of high-strength alloy steel, which significantly improves the chain tensile strength and safety factor.
Energy-saving applications are more efficient
·Increase the diameter of hydraulic pipelines, optimize the direction of pipeline joints, and extend the service life of hydraulic components.
·The hydraulic vehicle uses dual pump merging technology, which is energy-saving and efficient.
·Standard LED combination lamps are energy-saving and environmentally friendly, with long service life and high reliability.
·Standard load sensing gives priority to steering and reduces energy loss.
Carefully crafted for greater excellence
·The heat dissipation air duct is optimized and a larger aluminum plate-fin radiator is configured to greatly improve the cooling performance.
·The air filter alarm is standard to remind customers to maintain the air filter in time.
·The optimized double-thread locking mechanism makes locking and adjustment more convenient.
·The hydraulic vehicle is upgraded with a new intelligent shifting system to prevent starting in second gear.
Humanized design for more comfort

·The brake pedal and accelerator pedal are optimized to improve driving comfort.
·The small-diameter steering wheel greatly reduces the operating intensity and improves the driver's operating convenience.
·Humanized designs such as anti-slip metal pedals make operation more comfortable.

Specification

charac- teristic	1.1	Manufacturer(abbreviation)		CheersMetal	CheersMetal	CheersMetal	CheersMetal	CheersMetal	CheersMetal
	1.2	CheersMetalModel		CPC(D)40-AQ2	CPC(D)45-AQ2	CPC(D)50-AQ2	CPCD40-AS3	CPCD45-AS3	CPCD50-AS3
	1.3	Powerform		dieselfuel	dieselfuel	dieselfuel	dieselfuel	dieselfuel	dieselfuel
	1.4	Operationform		Seated	Seated	Seated	Seated	Seated	Seated
	1.5	Ratedloadcapacity	Q(kg)	4000	4500	5000	4000	4500	5000
	1.6	Loadcenterdistance	c(mm)	500	500	500	500	500	500
	1.8	Frontoverhang	x(mm)	555	555	555	555	555	555
	1.9	Wheelbase	y(mm)	2100	2100	2100	2100	2100	2100
weight	2.1	Deadweight	kg	6350(6550)	6550(6750)	6800(7000)	6350(6550)	6550(6750)	6800(7000)
	2.2	Axleloadatfullload,front/rear	kg	8850/1500	9700/1350	10500/1300	8850/1500	9700/1350	10500/1300
	2.3	Axleloadwhenunloaded,front/rear	kg	2900/3450	2900/3650	2900/3900	2900/3450	2900/3650	2900/3900
tire	3.1	solidrubber,superelastic,pneumatic,polyurethane		Pneumatictire	Pneumatictire	Pneumatictire	Pneumatictire	Pneumatictire	Pneumatictire
	3.2	Frontwheelspeciﬁcations		8.25-15-14PR	300-15-18PR	300-15-18PR	8.25-15-14PR	300-15-14PR	300-15-14PR
	3.3	Rearwheelspeciﬁcations		7.00-12-12PR	7.00-12-12PR	7.00-12-12PR	7.00-12-12PR	7.00-12-12PR	7.00-12-12PR
	3.5	Numberofwheels,front/rear(x=drivewheels)		2X/2	2X/2	2X/2	2X/2	2X/2	2X/2
	3.6	Frontwheeltrack	b10(mm)	1200	1200	1200	1200	1200	1200
	3.7	Rearwheeltrack	b11(mm)	1210	1210	1210	1210	1210	1210
size parameter	4.1	Mast/forkframetiltangle,forward/backward	α/β(°)	6/12	6/12	6/12	6/12	6/12	6/12
	4.2	Mastretractedheight	h1(mm)	2250	2250	2250	2250	2250	2250
	4.3	Freeliftingheight	h2(mm)	150	150	150	150	150	150
	4.4	Liftingheight	h3(mm)	3000	3000	3000	3000	3000	3000
	4.4a	Liftingheight(includingforkthickness)	h23(mm)	3050	3050	3050	3050	3050	3050
	4.5	Mastexpansionheight	h4(mm)	4300	4300	4300	4300	4300	4300
	4.7	Heightofoverheadguardrail	h6(mm)	2250	2250	2250	2250	2250	2250
	4.8	Seatheight	h7(mm)	1000	1000	1000	1000	1000	1000
	4.12	Heightoftractionpin	h10(mm)	390	390	390	390	390	390
	4.19	Totallength	l1(mm)	4305	4305	4305	4305	4305	4305
	4.20	Vehiclelength(excludingforks)	l2(mm)	3235	3235	3235	3235	3235	3235
	4.21	Overallwidth(frame/tire)	b1(mm)	1480/1430	1480/1490	1480/1490	1480/1480	1480/1490	1480/1490
	4.22	Forksize	s/e/l(mm)	1070/150/50	1070/150/50	1070/150/50	1070/150/50	1070/150/50	1070/150/50
	4.23	Forkinstallationlevel		3A	3A	3A	3A	3A	3A
	4.24	Forkcarriagewidth	b3(mm)	1380	1380	1380	1380	1380	1380
	4.31	Groundclearancebelowmast(noload)	m1(mm)	180	180	180	180	180	180
	4.32	Wheelbasecentergroundclearance	m2(mm)	235	235	235	235	235	235
	4.34.1	Workingchannelwidth,1000X1200pallet(1200forkplacement)	Ast(mm)	4685	4685	4685	4685	4685	4685
	4.34.2	Workingchannelwidth,800X1200pallets(1200placedalongtheforks)	Ast(mm)	4885	4885	4885	4885	4885	4885
	4.35	TurningRadius	Wa(mm)	2930	2930	2930	2930	2930	2930
	4.36	Innerturningradius	b13(mm)	960	960	960	960	960	960
Performance parameters	5.1	Travelspeed,full/noload,mechanicaltransmission	km/h	18/19	18/19	18/19	/	/	/
	5.1	Travelspeed,full/noload,hydraulictransmission	km/h	24/25	24/25	24/25	21/22	21/22	21/22
	5.2	Liftingspeed,full/empty,two-stagegantry	mm/s	500/530	500/530	500/530	/	/	/
	5.2	Liftingspeed,full/empty,two-stagegantry	mm/s	530/560	530/560	530/560	450/500	450/500	450/500
	5.3	Loweringspeed,full/empty,two-stagemast	mm/s	400/430	400/430	400/430	410/430	400/430	400/430
	5.6	Maximumtraction,full/noload,mechanicaltransmission	kN	32/20	32/20	32/20	/	/	/
	5.6a	Maximumtraction,full/noload,hydraulictransmission	kN	40/22	40/22	40/22	34/22	34/22	34/22
	5.7	Climbinggrade,full/noloadS2,mechanicaltransmission	%	22/20	22/20	22/20	/	/	/
	5.7a	Gradeability,full/noloadS2,hydraulictransmission	%	26/20	26/20	26/20	22/20	22/20	22/20
	5.10	Servicebrake		Hydraulic	Hydraulic	Hydraulic	Hydraulic	Hydraulic	Hydraulic
engine	7.1	EngineManufacturer		QuanchaiV35-88C41 (NationalIV)	QuanchaiV35-88C41 (NationalIV)	QuanchaiV35-88C41 (NationalIV)	MitsubishiS6S-G364CSFL (EuroA)	MitsubishiS6S-G364CSFL (EuroA)	MitsubishiS6S-G364CSFL (EuroA)
	7.2	EngineRatedPowerISO1585	kw	65	65	65	52	52	52
	7.3	Ratedspeed	rpm	2200	2200	2200	2300	2300	2300
	7.4	Numberofcylinders/displacement	cm3	4/3470	4/3470	4/3470	6/4966	6/4966	6/4966
	7.5a	MaximumTorque	N.m/rpm	350/1800	350/1800	350/1800	248/1700	248/1700	248/1700
	7.9	Vehiclesystemratedvoltage	V	12	12	12	24	24	24
	7.10	Startingbatterycapacity	V/Ah	12/120	12/120	12/120	12/80	12/80	12/80
Gearbox	8.1	Transmissiontype		Mechanical(Hydraulic)	Mechanical(Hydraulic)	Mechanical(Hydraulic)	Hydraulic	Hydraulic	Hydraulic
	8.2	Gear,forward/reverse		2/2(2/1)	2/2(2/1)	2/2(2/1)	2/1	2/1	2/1
	8.3	Gearshiftingmethod		Mechanical(Electro-Hydraulic)	Mechanical(Electro-Hydraulic)	Mechanical(Electro-Hydraulic)	Electrohydraulic	Electrohydraulic	Electrohydraulic
other	10.1	Workingpressureofattachments	Mpa	18.5	18.5	18.5	18.5	18.5	18.5
	10.2	AttachmentWorkFlow	L/min	60	60	60	60	60	60
	10.4	Fueltankcapacity	L	90	90	90	90	90	90
	10.8	KingpinspeciﬁcationsDIN15170		35	35	35	35	35	35
